bone saw

The saw blade safety cover and fixing device used in the bone sawing machine can be adjusted freely; The main transmission wheel is made of precision cast stainless steel, which is wear-resistant and has a long service life; The spacious waste bin device facilitates the unified storage and organization of unexpected materials after processing; The stable baffle can adjust the size of the required processing materials freely, suitable for small and medium-sized processing plants as well as individual users; Maximum cutting width: 235mm. Maximum cutting height: 300mm.

　　bone sawThe safety protection cover and fixing device using saw blades can be adjusted freely; The main transmission wheel is made of precision cast stainless steel, which is wear-resistant and has a long service life; The spacious waste bin device facilitates the unified storage and organization of unexpected materials after processing; The stable baffle can adjust the size of the required processing materials freely, suitable for small and medium-sized processing plants as well as individual users; Maximum cutting width: 235mm. Maximum cutting height: 300mm.

　　1、 Precautions before use

There should be no other debris on the workbench.

2. Check for any abnormal phenomena during operation after connecting the power supply.

3. The machine must be placed on a horizontal surface to avoid any danger caused by back and forth movements during use.

　　2、 Usage method

1. Adjust the guide block to the appropriate height according to the height and fix it. Adjust the thickness adjustment plate according to the required size of the meat pieces.

2. Press the green button on the power switch, and do not push the sawing object too much during operation, as it may cause the saw blade to fall off or be damaged.

3. The operator should stand in front of the machine and push the cut items horizontally and in a straight line. When replacing the saw blade, the teeth should be exposed outside the wheel. When 6 rounds are full, the leather cover should be exposed once.

4. Rotate the upper wheel by hand. If the saw blade runs inward, turn the adjustment screw counterclockwise. If the saw blade runs outward, turn the adjustment screw clockwise.

　　3、 Precautions

Due to the high-speed rotation of the band saw, it is also necessary to develop the habit of turning off the switch when pausing work.

2. If iron nails or other metal objects are carried in the cut, they may cause sawtooth cracking or damage, so attention should be paid to inspecting the cut surface during operation to ensure safe work.

3. Children are prohibited from approaching.

　　4、 Cleaning up

After completing the homework, it is necessary to clean it up because the meat residue and foam attached to the machine will become unhygienic over time, and the dry noise will increase during the next use.

　　5、 Diagnosis and repair of faults

1. The band saw often breaks. Reason: Poor quality of a band saw; b. The band saw is adjusted too tightly; c. Excessive force push or improper use, not in a straight line push

Repair:

a. Use a good band saw

b. Adjust the handle of the band saw appropriately to prevent it from becoming too rough. It is advisable to expose the rubber sleeve by tightening the spring once

2. The band saw derailed

Reason: a. The band saw is too loose b. There are foreign objects attached to the pulley area c. Improper use

Repair: Adjust the handle of the band saw to prevent it from becoming too loose, remove foreign objects attached to the pulley, and use it correctly

3. Other faults

Please consult with the agency and do not attempt to repair it yourself.
